LXNAV S10D and S100D Second Seat Repeater
LXNAV S10D / S100D Second Seat Repeater
General Description
LXNAV S10D / S100D Second Seat Repeater - In two–seat gliders it is possible to install the LXNAV S10xD rear seat device. The basic idea of the two-seat configuration is that both devices work independently from each other with the possibility of automatically exchanging various items of data (volume, Mc, polar…).
The LXNAV S10x can be expanded with one or more repeaters via the CAN bus. This allows both pilots in a two-seat glider to have independent control of all functions of each unit in the front or the rear seat.
By using a CAN bus system, a second seat device can be connected. The unit installed in the rear seat of the glider is independently powered and receives all the necessary data from the main unit. The communication between both units is exclusively via the CAN bus system (Remote stick, Compass module, Second seat device).
LXNAV S10D / S100D price varies depending on selection.
Use above dropdown box for selections and final price.
| Power Input | 10-28 V DC |
| Min Brightness (mA) | S10D: 90 at (12V) |
| S100D: 90 at (12V) | |
| Max Brightness (mA) | S10D: 140 at (12V) |
| 140 at (12V) | |
| Size and Weight: | S10D: 57 mm cut-out 61x61x48, 210 g |
| S100D: 80 mm (3.15") standard aircraft cut-out 81x81x45mm, 290 g | |
| Circuit Breaker | 3 AMP |
- S10 / S00D Second Seat Unit
- Y cable splitter (optional, only with compass or remote stick)
- Main 3m CAN cable
