Overview
LXNAV GPS Mouse
Manufacturer Part Number: GPS-UL
Related Products
Check items to add to the cart or
LXNAV GPS Mouse
General Description
LXNAV GPS Mouse - External GPS module for devices without integrated GPS.
This is a special order item. Please allow approximately 3 weeks LXNAV production time.
| Input Voltage | 8-36V |
| Flarm Connection | Standard Flarm pinout connection on RJ12 |
| Sensitivity | Acquisition -148dBm, cold start Reacquisition -160dBm Tracking -165dBm |
| GPS | 66 Channels |
| Start Up | Hot start: 1 second typical Warm start: 33 seconds typical Cold start: 35 seconds typical |
| Velocity Accuracy | Without aid : 0.1m/s DGPS(RTM,SBAS(WAAS,EGNOS,MSAS,GAGAN)):0.05m/s Without aid:0.1 m/s2 |
| Position Accuracy | Without aid: 3.0m 2D-RMS DGPS(RTM,SBAS(WAAS,EGNOS,MSAS)): 2.5m 2D-RMS |
| Acceleration Accuracy | Without aid:0.1 m/s2 DGPS(RTM,SBAS(WAAS,EGNOS,MSAS)):0.05m/s2 |
| Altitude | max. 18,000m (60,000 feet) |
| Velocity | max. 515m/s (1000 knots) |
| Acceleration | max. 4G |
| Working Temperature | -40 °C to +85 °C |
| Dimensions And Weight | Dimension: 134mm*62mm*33.9mm (5.276in*2.441in*1.336in) Weight: 270g |
