General Description
LXNAV Remote Stick Ergonomically designed remote stick for maximum comfort on long flights. 7 push buttons and a joystick button for easy screen navigation. One button can be customized with your most desired action. There are three versions: a standard version, a red start button version and a trim switch version. Every version can have an Oximeter module to measure the pilot’s saturation and heartbeat. It is compatible with all LX80xx and LX90xx units having V-series variometers. A special CAN version works with S-series variometers. It can be configured as single or second seat device.
Shapes
LXNAV Remote Stick price varies depending on selection.
Use above dropdown box for selections and final price.
| Power Consumption | 8-18V DC |
| Consumption at 12V | 60mA |
| Weight | 300 g |
RS485 (LX90X0, LX80X0)
- LXNAV Remote stick
- RS485 splitter
- Hex key
CAN (S8X, S10X)
- LXNAV Remote stick
- CAN-485 Remote adapter
- CAN splitter S8x cable
- Hex key
Remote Stick Sizes
| 19mm Remote Stick | DG, Schempp-Hirth, LAK, Antares |
| 20mm Remote Stick | LS, STemme, Apis, EB-29, Hph, Shark |
| 22mm Remote Stick | Jantar |
| 24mm Remote Stick | Schleicher, Pipistrel, Taurus, Alisport, EB-28, JS3 |
| 25.4mm Remote Stick | JS1 |
| 19mm With Trim | Schempp-Hirth M |
| 20mm With Trim | EB-29 |
