RAMI AV-801 WAAS GPS Antenna

General Description

RAMI AV-801 WAAS GPS Antenna - is designed specifically to meet FAA TSO-C190 specifications. Qualification testing includes meeting the requirements of RTCA DO-301 and DO-160G. The mounting footprint matches the standard ARINC found on many general aviation aircraft up to and including business jets.

Features

  • Designed specifically to meet FAA TSO-C190 specifications
  • Hemispherical radiation pattern
  • 1575.42 ± 10.23 MHz frequency

Max Weight 5.0 oz
Application Most aircraft up to and including business jets
Frequency 1575.42 ± 10.23 MHz
VSWR 1.5:1 Maximum
Polarization RHCP
Radiation Pattern Hemispherical
Impedance 50 Ohms Nominal
Gain 26.5 – 30.5 dB
DC Voltage 4.5 to 14.5 VDC
DC Current 40mA Typ. / 60mA Max
Noise Figure 2.5 dB
Selectivity 1315 – 1504.42 MHz -50 dB
1625.42 – 2000 MHz -50 dB
Connector TNC Female
FAA Approval TSO-C190
