In stock
$189.00
Overview
RAMI DME Transponder Antenna
Manufacturer Part Number: AV-74
Related Products
Check items to add to the cart or
RAMI AV-74 DME Transponder Antenna
General Description
RAMI AV-74 DME Transponder Antenna - is a broadband blade type antenna for transponder or DME application. The antenna housing is constructed of an acrylonitrile-styrene-acrylic (ASA) shell. The white color allows maximum performance without losses due to color pigments or unseen dirt. The antenna is supplied with cellular neoprene mounting pad and hardware.
Features
- This antenna is a direct replacement for the CI-105
- DME/Transponder
- Omni-directional
- Vertical polarization
- BNC female connector
- 960-1220 MHz
- 2.5 kW peak RF power
| Weight | 13.6 oz |
| Height | 3.4 in |
| Frequency | 960 MHz to 1220 MHz |
| Impedance | 50 Ohms Nominal |
| VSWR | 1.5:1 Maximum |
| Polarization | Vertical |
| Pattern | Omni-Directional |
| Connector | BNC (Female) |
| RF Power Capacity | 2.5 kW Peak |
| Color | Gloss White |
| FAA Approval | TSO-C66c, TSO-C74c |
