RA Miller DME Transponder Antenna
Manufacturer Part Number: AV-74-1
Related Products
Check items to add to the cart or
RAMI AV-74-1 DME Transponder Antenna
General Description
RAMI AV-74-1 DME Transponder Antenna - is a broadband blade type antenna for transponder or DME application. The antenna has longer mounting studs for thicker mounting locations. Its housing is constructed of anacrylonitrile-styrene-acrylic (ASA) shell. The white color allows maximum performance without losses due to color pigments or unseen dirt. The antenna is supplied with cellular neoprene mounting pad and hardware. The antenna is designed to operate at speeds up to 350 mph and altitudes up to 50,000 ft. It has a drag force of 0.09 lbs @ 250 mph. This antenna is a direct replacement for the CI 105-16.
Features
- Direct replacement for the CI-105-16.
- DME/Transponder
- Omni-directional
- Vertical polarization
- BNC female connector
- 960-1220 MHz
- 2.5 kW peak RF power
| Weight | 13.6 oz |
| Height | 3.4 in |
| Frequency | 960 – 1220 MHz |
| Impedance | 50 Ohms Nominal |
| VSWR | 1.5:1 Maximum |
| Polarization | Vertical |
| Pattern | Omni-Directional |
| Connector | BNC (Female) |
| RF Power Capacity | 2.5 kW Peak |
| Color | Gloss White |
| FAA Approvals | TSO-C66c, TSO-C74c |
