LXNAV Airdata Indicator
LXNAV Airdata Indictor
General Description
LXNAV Airdata Indicator - Indicates airspeed, altitude and vertical speed with an integrated high-precision digital pressure sensors. The unit has standard dimensions of 57mm or 80 mm diameter.
The Airdata indicator or ADI is a standalone unit designed to measure and indicate airspeed, altitude and outside air temperature. The unit has standard dimensions that will fit into the instrument panel with an opening of 57 mm or 80mm diameter.
The unit has integrated high-precision digital pressure sensors. The sensors are sampled 50 times per second. Real-time data is displayed on a QVGA 320x240 pixel 2.5-inch high (57mm) or 3.5-inch (80 mm) brightness color display. Three push buttons are used to adjust values and settings.
W&W typically stocks both 57 and 80mm LXNAV Airdata indicators.
Features
- An extremely bright 2.5" or 3.5" QVGA color display readable in all sunlight conditions with the ability to adjust the backlight
- Three push buttons are used for input
- Logbook
- 100 Hz sampling rate for very fast response
LXNAV ADI price varies depending on selection.
Use above Check Box for selections and final price.
| Size And Weight 80 mm | Height: 81 mm Width: 81 mm |
Depth: 53 mm Weight: ~270 g |
| Size And Weight 57 mm | Height: 61 mm Width: 61 mm |
Depth: 48 mm Weight: ~200 g |
| Chip | ARM Cortex-M4 160MHz | |
| Display |
2.5-inch (57mm ) sunlight readable 3.5-inch (80mm ) sunlight readable |
|
| 16 bit color display | ||
| 1200 cd brightness | ||
| 320-pixel-by-240-pixel resolution | ||
| ALS – ambient light sensor | ||
| Sensors | High resolution pressure sensors | |
| Connections | Serial port input/output on RS232 level (standard IGC 6 pin connector RJ11) | |
| Micro SD card | ||
| Buttons | 3 x Push buttons | |
| Storage | 2 GBytes of internal memory | |
| Integrated SD card reader | ||
| Certification | Not certified | |
| Consumption | At 12V (power input 8-32V) | |
| 90 mA – 140 mA | ||
| Material | Aluminum housing | |
| Circuit Breaker | 1 AMP |
- Airdata indicator (ADI)
- Power supply cable
- OAT probe
