TRIG VHF COM Antenna
Manufacturer Part Number: 02451-00
Typically Stocked Item
Trig TA10 VHF COM Antenna
General Description
Trig TA10 VHF Com Antenna - is a certified VHF Com antenna, designed to provide the best performance from Trig VHF radios. The TA10 is a ‘straight’ model and typically is located on the upper fuselage of the aircraft surface. With excellent electrical characteristics, the antenna has an efficient aerodynamic design that includes a solid four-bolt mounting base. Ideal for use in a wide range of GA types, including high-performance aircraft up to 350mph and 50,000 feet. Make your Trig radio installation complete by adding a TA10.
W&W typically stocks Trig TA10 VHF Com Antennas.
| Model | Type | Frequency | Impedance | VSWR | Polarization | Pattern | Connector | RF power | Height /Weight |
| TA10 | VHF Com Antenna – ‘straight’ type | 118 – 137 MHz | 50 Ohms nominal | 2.0:1 maximum | Vertical | Omni-Directional | BNC female | 30 Watts | 523mm / 20.6″ 226g / 8oz |
The TA10 ships with an installation kit, installation guide and an FAA 8130 certification / approval
Features
- Advanced aerodynamic design – proven with Trig VHF radios
- Suitable for most GA types, including high performance aircraft (up to 350 mph / 50,000 feet)
- Certified to FAA TSO C37d and C38d
- Solid four bolt mounting base
- Complete with installation kit
