In stock
$225.00
Overview
RAMI VHF Comm Vehicle Antenna
Manufacturer Part Number: AV-3
Related Products
Check items to add to the cart or
RAMI AV-3 VHF Comm Vehicle Antenna
General Description
RAMI AV-3 Comm Vehicle Antenna - is a general aviation, low profile, snap-in mounting quarterwave antenna for use on ground vehicles. It has a solderless cable connection at the antenna and is supplied with 17 ft. of cable and a PL-529 connector. The antenna is field tunable by simply cutting the whip to the required length.
Features
- Designed for use on ground vehicles
- 108-512 MHz frequencies
- Vertical polarization
- Omnidirectional pattern
- 50Ω impedance
- PL-259 connector & 17 ft. of cable included
| Max Height | 27.5 in (field adjustable) |
| Application | VHF Communications |
| Frequency | 108 – 512 MHz (Field Tunable) |
| Impedance | 50 Ohms Nominal |
| VSWR | 1.5:1 Maximum at Resonance |
| Polarization | Vertical |
| Pattern | Omnidirectional |
| Connector | PL-259 Male 17 ft. of cable |
| RF Power Capacity | 100 Watts |
