TOST Standard Hydraulic Hoses
TOST Standard Hydraulic Hoses
General Description
TOST Standard Hydrualic Hoses - TOST offers a large selection of standard hydraulic hoses. In addition to the individual fitted types of hydraulic hoses. We offer Polyflex hoses with low weight or Stahlflex hoses for tight bends and greater hose lengths.
Installation Notes
- Hydraulic hoses must be installed twist–free to prevent weakening of the material. If twisted hoses are put under pressure, they can work loose from their fittings.
- Hydraulic hoses must be laid with large enough bends to prevent pinching of the hose. Pinching reduces the cross–sectional area and impairs braking performance.
- The life expectancy of a hydraulic hose is reduced significantly by too small bending radi. Use hoses made of steelflex (material b) if you cannot avoid tight bends.
TOST Hydraulic Hose price varies depending on selection. Use above dropdown box for selections and final price.
|
P/N SKU |
Desc | Fluid | Material |
Length mm |
Connection |
| 058712 | Type 1 |
DOT4 Mil-H |
Stahlflex | 250 | straight pipe socket |
| 058716 | Type 1 |
DOT4 Mil-H |
Stahlflex | 600 | straight pipe socket |
| 058721 | Type 1 |
DOT4 Mil-H |
Stahlflex | 1120 | straight pipe socket |
| 058724 | Type 1 |
DOT4 Mil-H |
Stahlflex | 1240 | straight pipe socket |
| 058423 | Type 2 |
DOT4 Mil-H |
Polyflex | 300 | o/s: eye ring Ø 10 mm o/s: JIC04 spigot nut |
| 058765 | Type 2 |
DOT4 Mil-H |
Stahlflex | 500 | o/s: eye ring Ø 10 mm o/s: JIC04 spigot nut |
| 058766 | Type 2 |
DOT4 Mil-H |
Stahlflex | 600 | o/s: eye ring Ø 10 mm o/s: JIC04 spigot nut |
| 058490 | Type 2 |
DOT4 Mil-H |
Polyflex | 900 | o/s: eye ring Ø 10 mm o/s: JIC04 spigot nut |
| 058330 | Type 3 |
DOT4 Mil-H |
Polyflex | 300 | o/s: eye ring Ø 10 mm o/s: JIC04 spigot nut |
| 058350 | Type 3 |
DOT4 Mil-H |
Polyflex | 500 | o/s: eye ring Ø 10 mm o/s: JIC04 spigot nut |
| 058360 | Type 3 |
DOT4 Mil-H |
Polyflex | 600 | o/s: eye ring Ø 10 mm o/s: JIC04 spigot nut |
| 058375 | Type 3 |
DOT4 Mil-H |
Polyflex | 750 | o/s: eye ring Ø 10 mm o/s: JIC04 spigot nut |
| 058380 | Type 3 |
DOT4 Mil-H |
Stahlflex | 850 | o/s: eye ring Ø 10 mm o/s: JIC04 spigot nut |
| 058390 | Type 3 |
DOT4 Mil-H |
Polyflex | 900 | o/s: eye ring Ø 10 mm o/s: JIC04 spigot nut |
| 058310 | Type 4 |
DOT4 Mil-H |
Polyflex | 700 | both sides eye ring Ø 10 mm |
| 058366 | Type 5 |
DOT4 Mil-H |
Polyflex | 600 | for Janus |
Hydraulic Hoses Just as important as the brake components (master cylinder, brake assembly) is their connection with each other. Here should only be used high-quality hydraulic hoses, which are adequate for the specific fluid and for the arising operational and maximum pressure. With our hoses, ready manufactured for you, we offer you for every application and for every type of connection the correct hydraulic hose. Stahlflex hoses
Steelflex Hoses are the standard for highly stressed hydraulic systems how they get employed in the scope of aviation, motor sport or industrial plants. The multilayered structure of steelflex hoses (high pressure stable Teflon core and encasing stainless steel meshwork) provide tightest bending radii for very high operating pressure, without pressure loss also in extended hose lengths. A special feature of our steelflex hoses are the pressed-in connection fittings. The pressing process provides a maximum of leak tightness, also after a long time of operation under high hydraulic pressure.
TOST Hydraulic Hoses are a special order items. Please allow approximately 4 weeks for delivery.
Always use TOST Tires and Tubes when available.
See "Tech Data" tab for Description, Material and Technical Data.
See "Docs" tab for "TOST Tire, Tube & Wheel Selection Guide".
