TOST Master Cylinder HBG

050100, 050101

TOST Master Cylinder HBG

General Description

TOST Master Cylinder HBG - is the smallest brake cylinder for an integrated mounting to the control stick. Due to high quality materials and optimized pressure sealings it ensures a fast response characteristic and a very good modulation of braking force.

Use above selection for TOST Master Cylinder HBG fluid type.

HBG

P/N

SKU

Desc Fluid

App

(Suitable

Brake

Assembly)

Max Op

Press Bar

Con

Thread

Weight

g

050100

6285

HBG DOT4 BZT, BZT2,
30-9, 30-63A
100 M10X1 125

050101

6286

HBG

Mineral

Fluid

BZT, BZT2,
30-9, 30-63A
100 M10X1 125

TOST recommends the use of their thin and high flexible hydraulic lining Stahlflex (p/n 058002) for the feed and the pressure line, if the master cylinder is mounted to the control stick.

Master cylinder are the components in a hydraulic brake system, that produce the necessary brake respectively hydraulic pressure to push the brake linings against the brake disk. In addition to our brake assemblies, we manufacture a wide variety of master cylinders, available  from stock, which can be used in different combinations. In general, three types of master cylinder can be classified:

  • Hydraulic brake lever, which can be mounted directly to the control stick. The actuation is carried out directly by the pilot.e.g.: HBG, HBGD, HBGSH
  • Rudder pedal master cylinder, which can be mounted to additional small pedals on the rudder pedals or at a user-defined place in the fuselage. If the installation is not realized at the rudder pedals, the actuation has to be realized with a bow- den cable or push-rods. e.g.: PHBZ, 10-30
  • Universal master cylinder for user-defined installation in the fuselage. The actuation has to be realized with a bowden cable or push-rods. e.g.: Form 7

TOST Master Cylinder HBG is a special order items. Please allow approximately 4 weeks for delivery.

Always use TOST Tires and Tubes when available.

See "Tech Data" tab for Description, Application and Technical Data.

See "Docs" tab for "TOST Tire, Tube & Wheel Selection Guide".
