Tefzel Wire 18 Gauge (M22759)

Tefzel 18 Gauge Wire (M22759 & M27500)

General Description

Tefzel 18 Gauge Wire - Mil–Spec ETFE Insulated Electric Wire. Tefzel is a ethylene-tetrafluoroehtylene (ETFE) insulation. Tefzel is light, thin, resistant to abrasion, fuel, most chemicals, cuts and oil. It's designed for aerospace applications where dimensional tolerance, weight, and mechanical durability are required. The insulation is rated to 150°C (302°F). This wire exhibits high chemical and radiation resistance. This spec (M22759/16) is a tin plated copper conductor which offers a cost savings over the silver plated high strength copper alloy which is available on M22759/17.

M22759/16-18-X - is a Tin Plated Copper, Single Layer of Extruded ETFE Jacketed Wire, 150°C.

M27500-18TG1T14 - is a 1 Conductor cable with Tin coated round copper shielding and Tefzel jacket with an M22759/18 inner conductor

M27500-18TG2T14 - is a 2 Conductor cable with Tin coated round copper shielding and Tefzel jacket with an M22759/18 inner conductor.

This wire is commonly used in MIL-Spec and Aerospace applications.

Please note: wire is sold PER FOOT and is pulled from a large spool. It is not delivered to you on a spool or core, it comes loosely coiled in a plastic bag.

Tefzel Wire is cut to order and is non-refundable.

Tefzel Wire is sold PER FOOT. Price varies depending on selection above. Enter number of feet in quantity above. Use above dropdown box for Tefzel 18 Gauge Wire selection and final price.
