JJ033 Microphone Jack
Manufacturer Part Number: S12B
Related Products
Check items to add to the cart or
JJ033 Microphone Jack
General Description
JJ033 Microphone Jack - .206-inch jack connectors are designed for applications requiring polarization to prevent insertion of incorrect equipment. These Littel Plug® phone plugs feature a sleeve and a tip diameter of .206 inches.
This .206 open frame jack has a 3-connector stereo plug and .210 inch jack inside diameter. Mates with Switchcraft plug S267 .206 3-conductor, solder plug.
W&W typically stocks JJ033 Microphone Jacks.
- Nickel-plated, brass body mounting brushing
- Copper alloy ring terminal
- tin-coated, copper alloy sleeve terminal
- Phenolic rigid plastic insulators
- Nickel-plated, copper alloy jack washer
- Nickel-plated, copper alloy hex nut
- RoHS compliant
| Width | 0.75 in |
| Mounting Depth | 1 in |
| Plug Diameter | .210 in |
| Insertion Force | 7 lb (commercial plug) |
| Withdrawal Force | 1 lb (commercial plug) |
| Contact Resistance | 0.030Ω, maximum |
| Insolation Resistance | 10,000 MΩ |
| Dielectric withstanding Voltage | 500V, 60 Hz (rms) AC |
| Contact Rating | 1A, 25 VDC |
