Peiker TM170 Dynamic (Unamplified) Gooseneck Microphone
SKU
3347, 3348
In stock
$249.00
Overview
Peiker TM170 Dynamic (Unamplified) Gooseneck Microphone
Related Products
Check items to add to the cart or
Peiker TM170 Dynamic (Unamplified) Gooseneck Microphone
General Description
Peiker TM170 Dynamic (Unamplified) Gooseneck Microphone - Unidirectional noise canceling head, matte black housing and gooseneck. Available in two lengths 15" or 23". This Gooseneck Microphone is compatible with Becker AR6201 and FUNKE FSG 2T. See "Mic / Radio Selection Guide" for more radio types.
Characteristics
- Dynamic microphone capsule
- Unidirectional noise canceling
- Rugged housing
- Mounted on a 15" or 23" Gooseneck
W&W typically stocks Peiker TM170 Gooseneck Microphone.
Peiker TM170 price varies depending on selection above.
| General Data |
| Dimensions | 400 mm Length (15.7″), 24 mm housing diameter 613 mm length (24.1″), 24 mm housing diameter |
| Weight | 213 g (7.5 oz) 496 g (17.5 oz) |
| Connection | 2–wire cable shielded, 1.8 m, without connector |
| Storage Temperature | –30ºC to +70ºC (–22ºF to +158ºF) |
| Operation Temperature | –20ºC to +60ºC (–13ºF to +140ºF) |
| Microphone |
| Frequency range | 150 Hz to 12 kHz at –10 dB |
| Sensitivity | 1 mV/Pa (–60 dBV/Pa ± 3 dB) |
| Impedance | 200 kΩ ± 20 % at 1 kHz |
| Directivity | Cardioid (at 1 kHz; 180° –20 dB) |
- Red Wire: Mic+
- Yellow Wire: Mic- or Mic Ground
- Braid: Shield (connect to Mic- or Mic Ground)
| Radio | PEIKER TM168 SKU 3344 |
PEIKER TM170 SKU 3347 |
PEIKER ME510 SKU 3349 |
BECKER DYN BOOM MIC SKU 1399 |
F.U.N.K.E. DYN. GOOSENECK MIC SKU 1727 |
| Becker AR6201 |  |
|
|
||
| f.u.n.k.e. FSG 2T | |
|
|||
| Microair M760 | |
|
|||
| Flightline FL760 | |
|
|||
| Trig TY91 | |
|
