COMANT ComDat VHF/GPS WAAS Antenna
Manufacturer Part Number: CI 2580-200
Related Products
Check items to add to the cart or
Comant CI 2580-200 ComDat VHF/GPS WAAS Antenna
General Description
Comant CI 2580-200 ComDat VHF/GPS WAAS Antenna - is designed meet specific GPS WAAS Gamma 3 requirements of the Garmin G1000 system. This ComDat antenna provide 80 dB of VHF harmonic suppression, which allows VHF and GPS operation in one radome without the use of in-line filters. This antenna has passed the demanding direct effects of lightning environmental testing. The Gamma 3 WAAS allows for primary navigation using GPS for all phases of flight, including precision LPV approaches.
Features:
- VHF 118 MHz – 137 MHz
- GPS 1575.42 MHz
- 26.5 dB Gain
- Not intended for use with portable GPS receiver systems
| Weight | 0.6 lb, maximum |
| Connectors | VHF – BNC / GPS – TNC |
| Certifications | RTCA Env. DO-160D TSO C169(Class C,D,E,3,4,5,6) C144 |
| VHF SPECIFICATIONS: | |
| Frequency |
118 MHz – 137 MHz |
| VSWR | 2.5:1, maximum |
| Polarization | vertical |
| Radiation Pattern | Omni-directional |
| Impedance | 50Ω |
| Power Rating | 50 watts |
| GPS PREAMPLIFIER SPECIFICATIONS: | |
| Frequency |
17575.42 ±3 MHz |
| VSWR | 1.5:1, maximum |
| Radiation Pattern | hemispherical |
| Impedance | 50Ω |
| Gain | 26.5 dB – 30.1 dB |
| DC Voltage | 4 VDC – 24 VDC |
| DC Current | 40 mA, typical (60 mA, maximum) |
| Noise | 2.5 dB, maximum |
