Artex Tri-Band Rod Antenna
Manufacturer Part Number: 110-320
Related Products
Check items to add to the cart or
Artex Tri-Band ELT Rod Antenna Dual Output 110-320
General Description
Artex Tri-Band ELT Rod Antenna Dual Output 110-320 - is designed with a glass-reinforced, polyester housing and uses proprietary Tri-Band technology to provide signal transmission on 121.5, 243, and 406 MHz with 10 dB of isolation between ports.
Features
- White
- Tri-Band technology
- Dual input BNC, TNC
- 121.5, 243, and 406 MHz frequencies
- Vertical polarization
- Omni-directional radiation pattern
- Tough glass reinforced polyester housing
- Designed to meet the Eurocae ED 62 flame test
| Weight | 0.45 lb |
| Height | 15.50 in. |
| Frequency | 121.5, 243 & 406 MHz |
| VSWR | 2.0:1 - 121.5/243 MHz, 1.5:1 - 406 MHz |
| Polarization | Vertical |
| Radiation Pattern | Omni-directional |
| Impedance | RF 50 OHMS (nominal) |
| Power | 25 watts |
| Material | Molded radome/fiberglass whip |
| Finish | Polyurethane enamel |
| Connector | BNC (female) for 121.5/243 MHz, TNC (female) for 406 MHz |
| Temperature | -55˚ C to + 85˚ C |
| Altitude | 50,000 ft |
| Color | White |
| Gasket | B31725(optional to order separately) |
