Overview
Artex C406-N ELT
Manufacturer Part Number: 453-5060
Artex C406-N Single Outlet ELT
General Description
Artex C406-N Single Outlet ELT- is an automatic fixed type ELT which transmits on 121.5, 243.0, and 406 MHz frequencies. In the event of a crash the ELT automatically activates transmitting the standard swept tone on 121.5 and 243.0 MHz. It also transmits a 406 MHz encoded digital message to the Cospas/Sarsat satellite system, which allows for rapid identification and reduces Search and Rescue response time.
Model C406-N is a single BNC output ELT with an automatic G-switch for fixed wing applications. Connects directly to aircraft navigation. Capable of custom programming with optional adapter.
- Operates on 121.5, 243, and 406 MHz frequencies for global coverage
- RF output
- Rod, whip, and blade antenna compatible
- Compatible with aircraft navigation system, supports ARINC 429
- Automatic or manual activation
- 5-year lithium battery
- Self tests: G-Switch Enabled, 406 MHz Power Antenna/Coax Connection, Position Data Present, Low Battery, and Presence of Navigation Data
Weight | 3.16 lb (1.43 kg), ELT transmitter 4.24 lb (1.9 kg), total weight with mounting frame assembly |
Dimensions | 11.74 x 3.9 x 3.82 in, with mounting hardware installed |
Model | C406-N |
Antenna | Not included |
Operating Frequencies | 406 MHz, 121.5 MHz, 243 MHz ±0.005% (A3X) |
Output Power | 406 MHz: 5W (520 ms/50 sec) for 24 hours @ -20°C to 55°C 121.5/243.0 MHz: 100 mW min (+20 dBm) for 50 hours @ -20°C to 55°C |
Output Connector | BNC Female (121.5/243.0/406 MHz) |
Activation | Automatic by 4.5 feet per second (2.3 G) Primary G-Switch or Manual Activation |
Battery | 5-year Lithium (LiMnO2, solid cathode), Replacement Battery Part No. 452-0133 |
Temperature Certified to | Operating: -20°C to 55°C, Storage: -55°C to 85°C |
Remote Switch | Not included |
- C406-N ELT
- Lithium battery
