LX Navigation LX 10K Vario Navigation System DEALER DEMO
SKU
7115DD
In stock
Special Price
$2,265.00
was
$3,019.00
Overview
LX Navigation LX10K
With 80mm Digital Vario
Manufacturer Part Number: LX02000220
Related Products
Check items to add to the cart or
LX Navigation LX 10K Vario Navigation System
With 80mm Digital Vario
Dealer Demo
LX Navigation LX 10K Vario Navigation System - features the biggest digital display in 80 mm navigation instrument. Always in pair with vario indicator, pilots can choose between digital and analog, which can be 57 or 80 mm.
Features:
- 3.5" transflective technology sunlight readable display on the main unit
- Integrated G-meter (g-forces recorder)
- 3-axis gyroscope
- 3-axis accelerometers
- 50ch GPS receiver as an integral part of the system
- Completely new design using latest pressure transducer technology
- Extremely fast vario data acquisition
- Rotary knobs with push functions, for simple and effective handling
- Nearly unlimited memory space for flight recorder
- ENL (Environment Noise Level) sensor
- 5 user defined status inputs (SC, VP, gear, brakes and ballast)
- OAT probe input (outside air temperature)
- Internal beeper (for Flarm warning)
- Flarm port (input of Flarm data)
- User port for PDA/PNA/Radio/transponder, supplies navigation and Flarm data to PNA/PDA
- WiFi interface
- Bluetooth interface
- Voice module as an integrated part of the system
- CAN Bus, for connection to LX Zeus or other LX devices.
- External SD Card interface, for firmware updates, flight downloads and TP/TSK/APT/Airspace transfers
- Built-in rechargeable battery provides three to five hours of autonomy
- Internal battery is charging whenever connected to main power
- Pre-loaded polar database
|
Screen Size and Orientation |
Portrait |
|
Flight Recorder |
IGC (International Gliding Commission) approved flight recorder ENL (environmental noise level) for combustion engines |
|
Buttons and Handling |
2 marked buttons BOX – Change the NavBoxes on navigation pages MC – Enter quick MacCready, Bugs and Ballast menu 2 Push-rotary knobs Left – Zoom in/out Right – Move through pages |
|
Connectivity |
RJ12 SD CARD port RJ45 CAN port RJ12 INPUTS port RJ12 USER port RJ12 FLARM port 2,5 mm jack OAT port 3,5 mm jack AUDIO port 12 V power cable with connector SMA BLUETOOTH/WIFI antenna connector SMA GPS antenna connector |
|
Main Unit Size |
80mm / 2.5" |
|
Vario Indicator |
Analogue 57 (standard) / Digital 57 / 80 |
|
Accessory Options |
AHRS / Joystick / Flaps sensor |
LX 10K
Vario indicator (Analog vario indicator 57 is default)
Accessories pack:
- 16 GB Micro SD card
- OAT probe with 2,5 mm jack
- Audio speaker with 3,5 mm jack
- Inputs interface with RJ12 connector
- 40 cm CAN-BUS cable
- Bluetooth/WiFi antenna with SMA connector
- GPS antenna with SMA connector
Functions:
- Variometer, TE compensation (TE probe or electronic compensation).
- Speed-to-fly function
- Final glide calculator based on GPS data (for TP, APT, TSK and NRST)
- Complete TP/APT/TSK, NRST navigation with airspace information and warnings
- Highest level IGC approved flight recorder (find the IGC approval here)
- Flarm radar screen
- Thermal assistant screen
- System extensions: Second seat configuration, Remote control operation (LX Joy)
- Logbook
- Flight information with Barograph
- Multi pilot support
- Accurate wind calculation in straight flight and circling
- Voice announcement
- User warnings
