IN STOCK Paradigm (Strong) 306 Squadron Seat Para-Cushion Parachute
In stock
From $3,700.00
To $4,479.00
IN STOCK
Paradigm (Strong) 306 Squadron Seat Parachute
Paradigm (Strong) Para-Cushion 306 Squadron Seat STOCK Parachute
General Description
Paradigm (Strong) 306 Squadron Seat Parachute is designed to be used with bucket-style seat pans found in most warbirds with little or no headroom restrictions.
306 measures 13″ (33 cm) front–to–back by 16.5″ (42 cm) side–to–side by 6.5″ (16.5 cm) thick in the seat; 1.5″ (3.75 cm) thick throughout the back.
306 Squadron Seat comes with: Harness/Container Standard Harness is (3) B–12 Snaps (One in the Chest and one on each leg), Mid-Lite Parachute (Standard), Ripcord, Seat Cushion, Lil Grabber Pilot Chute, and Carry Bag.
The pack and cushion combination is shaped to fit fully into the seat to provide a large, stable, and comfortable seating area for the pilot. The harness is fully adjustable in the main lift webs (vertical straps), as well as in the lumbar area to ensure proper fit, provide support, and remain comfortable.
Stock Paradigm (Strong) 306 Parachutes
Please refer to the “Customize and Add to Cart” section for currently available models and estimated shipping dates. Harness configurations and colors are specific to each listed item and cannot be substituted.
Wings & Wheels places orders for Paradigm 306 Parachutes well in advance to help minimize lead times for our customers. These parachutes are full MSRP pricing.
- Parachutes listed as “AVAILABLE” are in our inventory, require final packing, and typically ship within approximately one week.
- Parachutes listed with an “ETA” include estimated availability dates based on projected shipping schedules provided by Paradigm. Please note that all estimated dates are subject to change.
Please note that selecting additional options may increase shipping time.
“Stock” parachutes are sold on a first-come, first-served basis. If another customer purchases the same parachute before your order is processed, we will contact you promptly with an updated estimated shipping date.
If you have any questions or need help ordering your Paradigm Parachute, please call (208) 994–4110 or email [email protected].
Travel Cushion and Lumbar Pad recommended.
Paradigm 306 Squadron Parachute price varies
depending on selections.
| Container Width | 16.5" (40 cm) |
| Thickness | 6.5" (7 cm) |
| Weight | 19.95 Pounds (8.8 kg) |
| Recommended Pilot Weight | Up to 254 Pounds |
| TSO'd |  |
26' Mid-Lite Canopy (Standard)
The 26' Mid-Lite is a highly reliable 24 gore canopy, tested to a 5000 lb shock load, built to withstand the rigors of an emergency bail-out. In production since 1987 the Mid-Lite has proven time and time again that it is the most rugged and reliable reserve you can
| Canopy Shape | Conical |
| Size | 26' |
| Number of Gores | 24 |
| Line Length | 17'6" |
| Panels Per Gore | 4 |
| Suspension Line Material | Braided Nylon |
| Suspension Line Strength | 425 lbs |
| Canopy Material | 30-50 cfm (PIA-C-44378d) |
| Turn Speed | Approx. 7 sec |
| Forward Speed | 6-8 mph (10-12 km/h) |
| Opening Time | 1.1 - 2.3 sec |
| Rate of Descent | 16.5 fps @ 200 lbs (5.0 m/sec) |
| Canopy Weight | Approx. 7 lbs |
| Maximum Weight | 254 Pounds |
30' Lo-Po Canopy (Optional)
Certified to FAA TSO C-23f, the 30 Foot Lo-Po is rated for exit weights up to 300 lbs (136.08 kg) and deployment speeds up to 175 knots (90.03 m/s). Available in 303, 304, 305, 306, 311. Standard in L-39 Chair.
| Canopy Shape | Conical |
| Size | 30' |
| Number of Gores | 26 |
| Line Length | 20' |
| Panels per Gore | 5 |
| Suspension Line Material | Braided Nylon |
| Suspension Line Strength | 650 lbs |
| Canopy Material | 30-50 cfm (PIA-C-44378d) |
| 360° Turn Rate | 7-8 sec |
| Forward Speed | 7 mph |
| Opening Time | 2 sec |
| Rate of Descent | 21.1 fps @ 237 lbs (6.4 mps) |
| Canopy Weight | Approx. 12 lbs |
| Maximum Weight | 300 lbs (136 kg) @ 175 knots |
The Para-Cushion Series
Why Practice?
Parachute Preflight
Caring for Your Parachute
Standard Harness and Aerobatic Harness / How to Gear Up
Egress Procedures
Parachute Deployment
How to Steer your Parachute and Land
Para-Cushion Save
|
Custom Embroidery Customize your Para-Cushion with your aircraft tail number, call sign, or anything you can imagine! Space provided 6" X 2.5", up to 6 characters (additional charges apply for digitizing logos or graphics). |
 |
|
Capewell Riser Release Allows you to release the canopy once you have landed in case of high winds, water or tree landing. |
 |
|
Sheepskin Back Pad Sheepskin keeps you warm in the winter and cool in the summer. Natural or Black. |
 |
|
Lumbar Support Pad A rounded Tempor Foam pad that attaches to the backpad. Adjustable to just the right position in the small of your back. |
 |
|
G-Pad Cushion An extra back cushion that wraps around your side keeping the parachute back pad firmly in place. For use when flying high G maneuvers. |
 |
|
Static Line A 15' Static Line that can be attached to a structural brace in the aircraft. Upon egress the static line will pull tight and open the container, releasing the pilot cute and parachute. |
 |
|
30' Lo-Po Canopy Certified to FAA TSO C-23f, the 30 Foot Lo-Po is rated for exit weights up to 300 lbs (136.08 kg) and deployment speeds up to 175 knots (90.03 m/s). Available in 303, 304, 305, 306, 311. Standard in L-39 Chair. |
 |
Features
-
13" (33 cm) front-to-back by 16.5" (42 cm) side-to-side by 6.5" (16.5 cm) thick in the seat*; 1.5" (3.75 cm) thick throughout the back
-
Weighs approximately 19.5 lbs (8.85 kg)**.
*with 26 FT Mid-Lite canopy; cushion thickness is adjusted to maintain 6.5" (16.51 cm) thickness with 30 FT Lo-Po canopy
**with 26 FT Mid-Lite canopy; 24 lbs (10.89 kg) with 30 FT Lo-Po canopy
-
The pack and cushion combination are shaped to fit fully into the seat to provide a stable and comfortable seating area for the pilot.
-
Choose our Standard Harness or the Aerobatic Harness at no additional charge.
-
TSO - C23c cat. B & SAE AS-8015A (w/26 FT Mid-Lite)
-
TSO - C23f & SAE AS-8015A (w/30 FT Lo-Po)
306 Seat Includes
- Harness/Container
- Mid-Lite Parachute (Standard) or 30 FT Lo-Po (Optional)
- Ripcord
- Seat Cushion
- Lil Grabber Pilot Chute
- Carry Bag
