Euro Style Terminal Block
4, 8 or10 Position
Euro Style Terminal Block
General Description
Euro Style Terminal Blocks are commonly used in sailplane wiring. They have recessed screws within the housing preventing short circuits. Each block contains many mounting hole options for easy installation.
Feed-Through Flat Base Eurostrips, cULus Recognized, VDE and CE Approved Compact, easy to use double-row tubular screw terminal strips are a safe, cost effective alternative to barrier strips. Dead front design. Supplied with wire protector. White polyamide 6.6 housing. 300 V, 30 A, 24-10 AWG. Pole Spacing: 10 mm (0.39"). Mounting Hole Diameter: 3.6 mm (.14"). Width: 20 mm (0.79").
W&W typically stocks Euro Sytle Terminal Blocks.
Euro Style Terminal Block price varies depending on selection above.
| 4 Position | 8 Position | 10 Position | |
| Color | White | White | White |
| Current Rating | 30 A A | 30 A A | 30 A A |
| Diameter, Mounting Hole | 3.6 mm | 3.6 mm | 3.6 mm |
| Dimensions | 36mm L x 20mm W x 14.9mm H | 76mm L x 20mm W x 14.9mm H | 96mm L x 20mm W x 14.9mm H |
| Number of Poles | 4 | 8 | 10 |
| Number of Rows | Double | Double | Double |
| Pin Spacing | 10mm | 10mm | 10mm |
| Primary Type | Euro Style | Euro Style | Euro Style |
| Special Features | High Voltage | High Voltage | High Voltage |
| Stripping Length | 6 mm | 6 mm | 6 mm |
| Torque | 7 lbs. | 7 lbs. | 7 lbs. |
| Voltage Rating | 300 V V | 300 V V | 300 V V |
| Wire Size | 24-10 | 24-10 | 24-10 |
