Overview
RG316 Coax Cable
MIL-DTL-17J
Related Products
Check items to add to the cart or
RG 316 Coax Cable
M17/113–RG36 MIL–DTL–17J
General Description
RG 316 Coax Cable - are constructed with either solid or stranded silver plated conductors insulated with an extruded PTFE (polytetrafluoroethylene) dielectric. The outstanding electrical and mechanical properties of PTFE over a broad range of temperatures and frequencies make these Thermax/CDT coaxial cables the standard for a wide range of military and commercial applications.
RG316 is sold PER FOOT. Enter the number of feet in quantity above.
RG316 is cut to order and is non-returnable.
| Conductor Inches | SCCS 7/.0067″ 0.0201 |
| Dielectric Inches | PTFE 0.060 |
| Shields Inches | 36SC 0.078 |
| Jacket Weight | FEP–IX 0.098 |
| Weigh lb/ft | 0.012 |
| Imp ohms | 50 ± |
| Vp % | 69.5 |
| Cap. pF/ft | 29.4 |
| Max Oper. Volts vrms | 1200 |
| Temp Range | –67 +392 |
| Jacket Type | Fluorinated Ethylene Propylene Type IX per MIL–C–17 |
