Dolba & Dolba Flarm Splitter
General Description
Dolba & Dolba Flarm Splitter Particularly low–attention distributor from measurement technology with SMA connection technology, for connecting two Flarm antennas.
Features
• Wideband, 700 to 2000 MHz
• Low insertion loss, 0.3 dB typ.
• High isolation, 30 dB typ.
• Up to 10W power input as splitter
• Excellent amplitude unbalance, 0.1 dB typ.
• Excellent phase unbalance, 1 deg. typ.
• Excellent VSWR, 1.1:1 typ.
• Rugged shielded case
Application
• Cellular
• GPS
• PCS/DCS
• Instrumentation
