Dolba & Dolba Flarm Splitter
Related Products
Check items to add to the cart or
Dolba & Dolba FLARM Splitter
General Description
Dolba & Dolba FLARM Splitter - Particularly low-attenuation distributor from measurement technology with SMA connection technology, for connecting two Flarm antennas.
Features
- Wideband, 700 to 2000 MHz
- Low insertion loss, 0.3 dB typ.
- High isolation, 30 dB typ.
- Up to 10W power input as splitter
- Excellent amplitude unbalance, 0.1 dB typ.
- Excellent phase unbalance, 1 deg. typ.
- Excellent VSWR, 1.1:1 typ.
- Rugged shielded case
Application
- Cellular
- GPS
- PCS/DCS
- Instrumentation
| Dimensions | 72 x 51 x 19 mm |
| Weight | 100 g |
| Power Input (as a splitter) | 10W Max |
