Comant ComData GPS WAAS Antenna
Manufacturer Part Number: CI 428-200
Related Products
Check items to add to the cart or
Comant CI 428-200 ComData GPS WAAS Antenna
General Description
Comant CI-428-200 ComData GPS WAAS Antenna - is specifically designed to meet the GPS WAAS Gamma 3 specifications required by the Garmin G1000 system and matches the standard ARINC footprint found on many twin engine and business jets. It meets the RTCA DO 160D operating standards including direct effects lighting. Gamma 3 WAAS allows for primary navigation using GPS for all phases of flight including precision LPV approaches.
Features:
- Meets GPS WAAS Gamma 3 specifications as required by Garmin's G1000 system
- Matches standard ARINC footprint on many twin engine business jets
- Allows for primary navigation with GPS during all phases of flight including LPV approaches
| Weight | 6.2 oz |
| Frequency | 1575.32 MHz ±3 MHz |
| Polarization | RHCP |
| Radiation patter | Hemispherical |
| Impedance | 50Ω |
| Gain | 26.5 dB to 30.1 dB @ 1575.42 MHz |
| DC voltage | 4 VDC to 24 VDC |
| DC current | 40 mA (typical) / 60 mA (maximum) |
| Noise figure | 2.5 dB (maximum) |
| Selectivity | -50 dB (minimum) @ Satcom 1626.5 MHz |
| Finish | Gloss white |
| Connector | TNC (female) |
| Mounting | Four-hole mounting pattern |
| FAA TSO | C144 |
| RTCA Env. | DO-160D |
