Paradigm (Strong) 314 RV-4 Seat Para-Cushion Parachute
In stock
From $3,039.00
To $5,073.00
Paradigm (Strong) 314 RV-4 Seat Para-Cushion Parachute
Fully Customizable: Harness, Color, and Options
Paradigm (Strong) Para-Cushion 314 RV-4 Seat Parachute
General Description
Paradigm (Strong) RV Seat Para–Cushion Parachute is designed to fit into the seat bottom recess in RV-4 and RV-8 aircraft with the factory cushion removed. Can be used in other aircraft in which a less rectangular-shaped seat is desired.
The Model RV4 Seat, measures 10″ (24.5 cm) front–to–back by 15.5″ (39.4 cm) side–to–side by 3.5″ (8.9 cm) thick in the seat; 1.5″ (3.75 cm) thick throughout the back.
The Model RV4 is designed to be used in place of a seat cushion. By using an additional Confor©Foam cushion, the seat thickness of the pack may be from 1″ (2.5 cm) to 6″ (15 cm) thick, depending on the type of airplane and how high the user desires to be in the cockpit.
RV-4 Seat comes with: Harness/Container, Mid-Lite Parachute, Ripcord, Lil Grabber Pilot Chute, and Carry Bag. Choose Standard Harness (3 B12's - one in the chest and one in each leg) or the Aerobatic Harness at no additional charge.
MSRP $3700.00
Please allow approximately 6-9 months for delivery of your custom Paradigm 314 parachute.
If you have any questions or need help ordering your Paradigm Parachute, please call (208) 994–4110 or email [email protected].
Hardware Options
 |
Standard Harness Standard Snap/V–Ring (B–12) – B–12 Snaps come as standard leg and chest strap hardware on all Strong parachutes. |
 |
Quick Ejector Quick Ejector Snap/V–Ring (QE) – Military Style hardware replaces B–12 snaps. Allows you to lift the gate and eject the hardware instead of reaching under and lifting. |
 |
COBRA Buckles AustriAlpin COBRA™ Quick Release – Light weight, low profile, strong patented AustriAlpin COBRA® quick releases are, without equal, the safest, most finely crafted, and strongest load bearing buckles available anywhere. They are also the only stab–lock style fastener in the safety products market that will not open while under load. |
 |
Aerobatic Harness Moves the adjustment points from your thigh to your chest. For use when flying high G Maneuvers. |
Paradigm (Strong) 314 RV-4 Seat price varies
depending on selection.
| Front to Back | 10" (24.5 cm) |
| Side to Side | 15.5" (39.4 cm) |
| Thick in the Seat | 3.5 (8.9 cm) |
| Thick Throughout Back | 1.5" (3.75 cm) |
| Weight | Approx 18.5 Pounds (8.4 kg) |
| Pilot Weight | Up to 254 Pounds |
| TSO'd |  |
26' Mid-Lite Canopy
The 26' Mid-Lite is a highly reliable 24 gore canopy, tested to a 5000 lb shock load, built to withstand the rigors of an emergency bail-out. In production since 1987 the Mid-Lite has proven time and time again that it is the most rugged and reliable reserve you can own!
| Canopy Shape | Conical |
| Size | 26' |
| Number of Gores | 24 |
| Line Length | 17'6" |
| Panels Per Gore | 4 |
| Suspension Line Material | Braided Nylon |
| Suspension Line Strength | 425 lbs |
| Canopy Material | 30-50 cfm (PIA-C-44378d) |
| Turn Speed | Approx. 7 sec |
| Forward Speed | 6-8 mph (10-12 km/h) |
| Opening Time | 1.1 - 2.3 sec |
| Rate of Descent | 16.5 fps @ 200 lbs (5.0 m/sec) |
| Canopy Weight | Approx. 7 lbs |
| Maximum Weight | 254 lbs (115 kg) |
The Para-Cushion Series
Why Practice?
Parachute Preflight
Caring for Your Parachute
Standard Harness and Aerobatic Harness / How to Gear Up
Egress Procedures
Parachute Deployment
How to Steer your Parachute and Land
Para-Cushion Save
|
Custom Embroidery Customize your Para-Cushion with your aircraft tail number, call sign, or anything you can imagine! Space provided 6" X 2.5", up to 6 characters (additional charges apply for digitizing logos or graphics). |
 |
|
Capewell Riser Release Allows you to release the canopy once you have landed in case of high winds, water or tree landing. |
 |
|
Sheepskin Back Pad Sheepskin keeps you warm in the winter and cool in the summer. Natural or Black. |
 |
|
Lumbar Support Pad A rounded Tempor Foam pad that attaches to the backpad. Adjustable to just the right position in the small of your back. |
 |
|
G-Pad Cushion An extra back cushion that wraps around your side keeping the parachute back pad firmly in place. For use when flying high G maneuvers. |
 |
|
Static Line A 15' Static Line that can be attached to a structural brace in the aircraft. Upon egress the static line will pull tight and open the container, releasing the pilot cute and parachute. |
 |
|
Travel Custion A zip on seat pad that allows the pilot to customize the height of their seat cushipn from 1" (2.5 cm) to 6" (15 cm). |
 |
Features
-
RV-4 Seat, measures 10" (24.5 cm) front-to-back by 15.5" (39.4 cm) side-to-side by 3.5" (8.9 cm) thick in the seat; 1.5" (3.75 cm) thick throughout the back.
-
RV-4 is designed to be used in place of the factory seat cushion. By using an additional Confor©Foam Travel Cushion tPilot height msy be customized by adding an additional 1" (2.5 cm) to 6" (15 cm).
-
Choose our Standard Harness or the Aerobatic Harness at no additional charge.
-
TSO - C23c cat. B & SAE AS-8015A (w/26 FT Mid-Lite)
314 RV-4 Seat Includes
- Harness/Container
- Mid-Lite Parachute
- Ripcord
- Lil Grabber Pilot Chute
- Carry Bag
Color Choices
 |
Standard Colors Standard Color Options – Red, Black, Olive Drab, Royal Blue, Navy Blue. Actual color may vary slightly depending on your screen. |
 |
Custom Colors Custom Color Option: Burgundy, Sage Green Smoke / Grey, Orange, Purple, Forest Green, Teal, Coyote Brown / Tan. By choosing Custom Colors, you may be charged a $100.00 customization fee. Actual color may vary slightly depending on your screen. Actual color may vary slightly depending on your screen. |
