Vinyl Instrument Tubing

General Description

Vinyl Instrument Tubing -  is strong, flexible and lightweight. 3/16″ inner diameter, 5/16″ outer diameter.

Color instrument tubing is a good way to separate by color code; Capacity = Yellow, Total Energy = Green, Pitot = Red and Static sources = Blue.

Vinyl Instrument Tubing price varies depending on selection. Enter number of feet in “Qty:”. Use above dropdown box for selection and final price.

RED, GREEN, YELLOW and BLUE TUBIG

ID 3/16"
OD 5/16"
Wall 1/16"/0.062"
Durometer hardness 68
Temperature range -17°F to 160°F
Max. working pressure @ 70°F 55 psi
Tensile strength: 798 psi (@ yield) 2370 psi (@ break)
Specific gravity 1.13
Brittleness temperature -67°F

CLEAR TUBING

ID  3/16"
OD 5/16"
Wall 1/16"/0.062"
Durometer hardness (shore A) 70
Temperature range -41°F to 140°F (Brittle at -41°F)
Working pressure @ 68°F 55 psi
Tensile strength 2000 psi
Specific gravity  1.20
Elongation at break 400%

W&W typically stocks all colors of Vinyl Instrument Tubing.

Vinyl Instrument Tubing is sold PER FOOT.
